Metalclad Consumer Units
The new range of Metalclad Consumer Units from Proteus Switchgear have been designed in conjunction with contractors and our in-house design team specifically to meet the requirements of BS 7671 – The Wiring Regulations.
With a curved design cover, rounded corners and a matt white finish, the consumer unit offers the home owner a discreet and modern product, whilst providing ample protection for today’s ever evolving market through our industry leading devices.
The all metal construction ensures compliance to Regulation 421.1.201, whilst the optional Surge Protection feature means you are up to date with the latest 18th edition regulations.
The Proteus metalclad range meets these requirements and offers additional features providing a more versatile product for the installing contractor.
Flush design, rounded corners and matt white finish for enhanced appearance
Removable door with spring loaded hinge and rubber stops for soft close
Removable key lock blank and key lock option available if desired
Multiple knockouts and new cable entry plate to prevent damage to cables
Numbered and coloured earth and neutral bar with built-in spirit level
Ample space on right-hand side to bring the meter tails in to the top of the isolator
Top Product Award 2025 from Professional Electrician Magazine
Proteus Consumer Unit Instruction Leaflet
Download the Instruction Leaflet for the Consumer Unit below:
ISOLATOR INCOMER UNITS
- Patented dual screw isolator
- Available range of outgoing circuits from 2 to 20 way
- Accepts 6kA & 10kA MCBs and RCBOs
- Optional Surge Protection Device (SPD) fitted
- Non-combustible enclosure
- Matt white RAL 9016 finish
- Flush fitting door & curved cover
- Removable door via spring loaded hinge
- 10 Year guarantee
RCD INCOMER UNITS
- 100A 30mA RCD incomer as standard
- Available range of outgoing circuits from 2 to 10 way
- Accepts 6kA & 10kA MCBs + 15kA
- Optional Surge Protection Device (SPD) fitted
- Non-combustible enclosure
- Matt white RAL 9016 finish
- Flush fitting door & curved cover
- Removable door via spring loaded hinge
- 10 Year guarantee
VARIABLE UNITS
- Patented dual screw isolator & 2x 100A RCDs
- Accepts 6kA & 10kA MCBs and RCBOs
- Optional Surge Protection Device (SPD) fitted
- Non-combustible enclosure
- Matt white RAL 9016 finish
- Flush fitting door & curved cover
- Removable door via spring loaded hinge
- 10 Year guarantee
METALCLAD ENCLOSURES
- 100A Isolator
- 100A RCD Incomer
- Accepts 6kA & 10kA MCBs and RCBOs
- Optional Surge Protection Device (SPD) fitted
- Non-combustible enclosure
- Matt white RAL 9016 finish
- Flush fitting door & curved cover
- Removable door via spring loaded hinge
The Proteus Consumer Unit Brochure
The Proteus Consumer Unit Animation
Watch our New Consumer Unit Animation to see all the features and benefits of our new board in more detail.
